U1000 Features and Benefits

توضیحات:

Yaskawa America, Inc. welcomes you to the U1000 Features and Benefits video.
Video Outline:
• Matrix Technology (0:51)
• Power Conversion Methods (2:20)
o Conventional Drive (indirect)
o Matrix Drive (direct)
• Regenerative Energy (4:37)
o Definition and example of regeneration
o Hold back torque
• Harmonic Distortion (8:25)
o Input current harmonics comparisons
• Other Features and Benefits (12:12)
• Near Unity Power Factor (12:34)
o Displacement power factor vs True power factor
o Standard drive vs U1000
• Greater System Efficiency (13:33)
o Less wiring, smaller footprint, energy savings
o Eco Mode
o Compact design/All-in-one package
• Variable 3-Level Output (16:39)
o Reduction in surge voltages and common mode current
• Expanded Motor Control (17:13)
o Permanent magnet control for SPM and IPM motors
• Capacities and Certifications (17:38)
o 240V and 480V classes available
• Software Features (19:32)
o Common operating features with the A1000 drive
o Power Monitors
• Hardware Features (21:41)
o Standard I/O and removable terminal card
o Available Options
o Serial Communications

This eLM is also available on the Yaskawa America, Inc. - Drives and Motion Division website (www.yaskawa.com).

Download at: https://www.yaskawa.com/pycprd/training/elearning-curriculum/tab0/link00
Yaskawa Doc ID: eLM.U1000.01
